Glass Bottle Crusher
Processing capacity: 150-1500 pieces/hour or customizable
Application scenarios: these glass bottle crushers are mainly applied for waste glass recycling stations, glass processing centers, pharmaceutical companies and alcohol manufacturers, glass manufacturing plants, bars, hotels, breweries, etc.
Applicable materials: crushing beer bottles, syrup bottles, glass beverage bottles, glass jars, automobile glass, window glass, vaccine glass bottles, infusion bottles, perfume bottles, cosmetic bottles, experimental utensils, etc.
What Is Glass bottle crusher
A glass bottle crusher or glass bottle pulverizer/ grinder/ shredder, is a machine used to crush glass bottles/ containers into sand, small pieces or powders. These glass crusher machines are commonly used in processes typically used to recycle, reuse or dispose of glass materials to process discarded glass containers into reusable raw materials. It’ ‘s specifically designed to provide crushing equipment and solutions for glass to sand. The crushed glass bottles are smaller in size, saving storage and transportation space. Our glass crushing machines are the perfect recycling solution for companies that are producing vast amounts of glass bottle waste.
The principle of glass bottle crusher: Usually, glass bottles are placed into the crushing chamber or area of a crusher, and then strong mechanical force is used to break the glass into small pieces or sand.
Types of Glass bottle crusher
Our glass bottle crushers are also available in different types of operation, including manual, semi-automatic and fully automatic models. Manual models require an operator to manually feed and control the crushing process, while semi- and fully-automatic models are more efficient and often include automatic feeding and discharge systems. JXSC provides six types of glass bottle crushers: small-large scale, mobile and cabinet-type, hammer crushing machines. An industrial crusher for various glass waste crushing, and it can be operated safely and easily using a universal power outlet. The specific glass crusher selection depends on glass products’ crushing particle size requirements.
Glass bottle crusher For Sale
GB101 - Mobile glass crusher
The glass bottle crusher is powerful crushing equipment in a small package that safely crushes waste glass bottles into sand. It can reduce the volume of glass bottles by 75%, thus greatly saving storage space. It can crush 5-10 glass bottles per minute, completely maintaining the material’s physical state.
Features of mobile glass crusher
- High-efficiency low-speed shearing type crushing
- Small size, easy to move, less dust
- Support continuous feeding
parameter
| Model | GB101 |
| Power | 1.5kW |
| Voltage | 220V/50Hz/optional |
| Tool materials | High quality alloy steel material |
| Control box | All electrical components have passed CE certification, with stable performance and long service life. |
| Processing capacity | 150~200kg/h |
| Machine materials | The main body is made of carbon steel, and the tools are made of high-quality alloy steel. |
| Discharge size | 5~15mm |
| Entrance size | 200mm*200mm |
| Size | 400*600*1200mm |
GB201 - Cabinet Type Glass bottle crusher
The GB201 crusher is a hand-fed, quiet-operating glass bottle crusher machine designed for small recycling and commercial applications. It can be installed under a standard bar or hotel counter, and the material volume can be reduced by 80%.
Features Of Cabinet-Type glass bottle crusher
- The final glass flakes are in a sandy state and can reach a fineness of 1mm
- High-efficiency rotary crushing, customizable screens
- Closed structure, excellent dustproof effect
parameter
| Model | GB201 |
| power | 1.5kW |
| Voltage | 220V/50Hz/optional |
| Crushing speed | 1450 rpm |
| Tool materials | High-quality alloy steel material; |
| control box | All electrical components have passed CE certification, with stable performance and long service life. |
| processing capacity | 150 ~ 200 pieces/hour |
| Machine materials | The main body is made of carbon steel, and the tools are made of high-quality alloy steel; |
| Discharge size | 8 ~ 20mm (powder) |
GB301 - Small Glass bottle crusher
The small glass bottle crusher, or vaccine bottle crusher, is a crushing machine specially designed and developed for small customers and individual private enterprises. It is commonly used to crush ampoule vials, penicillin, vaccine vials, etc. The main purpose is to prevent the reuse of pharmaceutical glass bottles through physical crushing.
Features of Small Glass bottle crusher
- "Z" shaped feed chute prevents particles from splashing during the crushing process;
- It can protect the safety during hand feeding process;
- The particle size of the crushed product is about 10mm.
parameter
| Model | GB301 |
| Voltage | 1~220V/50Hz |
| power | 1.5kW |
| plastic filling box | 500mm*400mm*360mm |
| Feed port diameter | 220*220mm |
| size | 600mm * 1000mm |
| processing capacity | 300kg/hour |
| Discharge size | Usually: 20~50mm, or customized |
| Machine weight | 130kg |
GB401 - Large Glass bottle crusher
GB401 glass bottle crusher is a multi-feed crushing machine and can accept a large number of glass bottles. It can crush 50-100 glass bottles in 1 minute. We can customize cutters and spacers for effective crushing force. After crushing, the glass bottle fragments are about 10-50 mm.
Features of GB401 - Glass bottle crusher
- Made of wear-resistant materials, it is suitable for long-term high-intensity crushing processes;
- Closed structure, strong safety performance;
- Automated control system can improve the convenience and efficiency of operation.
parameter
| Model | GB401 |
| power | 7.5kW |
| Voltage | 380V/50Hz/3 phase or customized |
| Tool materials | High quality alloy steel material; |
| control box | All electrical components have passed CE certification, with stable performance and long service life; |
| processing capacity | 1000 ~ 1500 pieces/hour; |
| Machine materials | The main body is made of carbon steel, and the tools are made of high-quality alloy steel; |
| Discharge size | 30~50mm; |
| Knife box size | 380mm * 360mm |
| gross weight | 750kg |
| size | 1100*960*1600mm |
GB220 - Mini glass crusher
This is a compact glass bottle crusher with simple design and operation, providing crushing solutions for various glass products in small and medium-sized bars, homes, hotels, etc. Mainly turns glass into a sharp-free sand-like material.
Features of Mini glass bottle crusher
- Screen size can be customized from 8-15mm;
- Compact and lightweight, easy to maintain;
- Low energy consumption, energy-saving and environmentally friendly machine.
Hammer glass crusher
The glass crusher can achieve coarse, medium and fine crushing of various glass materials simultaneously without secondary crushing and shaping, which is more worry-free. The hammer glass crusher machine adopts an advanced structural design and low noise. Hammer crusher has a built-in screening effect and can be molded at once, and the finished product is is one of the best aggregates.
Features of Hammer glass crusher
- Use high-efficiency hammer heads or hammer blades, usually designed with safety devices;
- Sturdy and durable, able to withstand the impact and wear caused by various glass bottles;
- The discharging granularity can be adjusted as needed, with strong adaptability;
- Not only used for pulverizing glass bottles, but also for crushing minerals, rocks, and aggregates; widely application and customizable
parameter
| Model | Input size(mm) | Output size (mm) | Capacity (t/h) | Power (kW) | Weight (t) |
| PC400 * 300 | <100 | <10 | 5-10 | 11 | 0.8 |
| PC600 * 400 | <120 | <15 | 10-25 | 18.5 | 1.5 |
| PC800 * 600 | <120 | <15 | 20-35 | 55 | 3.1 |
| PC1000 * 800 | <200 | <13 | 20-40 | 110 | 7.9 |
| PC1000 * 1000 | <200 | <15 | 30-80 | 132 | 8.65 |
| PC1300 * 1200 | <250 | <19 | 80-200 | 240 | 13.6 |
Why Choose JXSC Glass Bottle Crusher
Various types to choose
Manufacturer of mobile, cabinet, small, large scale and six types glass bottle crusher machine
Versatility Crusher
Adaptable to crushing various types and sizes of glass bottles; it can be used for fine crushing glass into sand.
Simple operation
Easily start the glass bottle crusher machine with a universal power outlet.
High strength and durability
Made of wear-resistant material, it can withstand long-term use and has a long service life.
Strong safety factor
The feeding port is automatically closed, sealed structure, strong safety and environmental protection.
Factory Price & Customizable
Low energy consumption, cost; customizable glass crushing equipment.
Application cases
GB201 Crusher For Crushing Glass bottle To Sand
GB220 glass bottle crushing machine Working Site
Small Beer bottle Glass Crusher Equipment application
JXSC Hammer Glass Crusher For Crushing beer bottle
