20TPH Mobile Placer Gold Wash Process Plant in Tanzania
We guarantee the high quality machine in the mineral processing industry, established in 39+ years of experience.
Project Info.
1.Raw ore: placer gold ore containing much clay
2. Capacity: 20TPH
3. Feed size: ≤100mm
4. Output size: 0-2mm
5. Location: Tanzania
Process
Feeding – Washing & screening – Gravity Separation
process flow
20TPH Mobile Placer Gold Wash Process Plant
This setup is a mobile type placer gold wash plant, it is configured with a trommel scrubber to remove oversized rocks and a centrifugal concentrator, shaking table, and sluice box to capture fine gold concentrates and gold nuggets. the trommel scrubber is designed with mobile wheels, easy to move. Also can be made stationary type as per request.
First, we use a loader to feed the raw material to the trommel scrubber, We made 2 layers of screens, 6mm and 20mm respectively. After washing and screening, transport the material above 20mm as waste sand by belt conveyor. Then the material between 6-20mm will be input into the gold sluice box by height difference to catch the gold particles. This is the first part we can get gold from. After the sluice box can use a shaking table for recovery again.
Next, we use a slurry pump to pump the last material below 6mm onto the centrifugal concentrator. Centrifugal concentrator can concentrate gold particles of 0-6mm. The pulp under the screen enters the shaking table through the pipe, the shaking table can concentrate the gold powder between 0-2mm. Finally, use a gold smelting furnace to get the gold bar.
Note: This mobile placer gold wash process plant is very suitable for recovering placer gold ore with contains sticky clay. If the raw ore doesn`t contain much sticky clay, we will recommend a trommel screen instead of a trommel scrubber.
The trommel scrubber, centrifugal concentrator, and shaking table can change to different models and increase quantity according to different capacities. Our sluice box can be designed with different lengths and widths like 2m, 4m, 6m length, 1m width, or 0.5m width. The capacity of placer gold wash plant can be customized as per request such as 10tph, 50tph, 100tph, etc. Contact us to get the equipment price and details!
