15TPH Zircon Sand Separation Plant In Kazakhstan

We guarantee the high quality machine in the mineral processing industry, established in 35 years of experience

minerals

  1. Raw ore: Fine sand with slime, mainly containing 70-80% silica sand, 3% zircon sand, 4% ilmenite, 4.5% hematite, a small amount of rutile
  2. Capacity: 15TPH
  3. Project location: Kazakhstan
  4. Input size: 0-2mm

Main Equipment

  • Spiral washer
  • Vibrating screen
  • Spiral chute
  • Shaking table
  • Magnetic Separator
  • Electric Separator
  • Belt Conveyor

process flow

15TPH Zircon Sand Separation Plant In Kazakhstan

Customer requirements: The raw ore is a very fine placer containing slime, and the ore needs to be washed first. By gravity separation to remove light silica sand and waste sand. Then magnetic separation to remove magnetic minerals, and finally electric separation to remove rutile To improve the quality of zircon sand.

This is a Kazakhstan 15t/h zircon sand processing plant. The whole set of equipment is equipped with: spiral washing machine, vibrating screen, belt conveyor, slurry pump, spiral chute, magnetic separator, shaking table, electric separator.

1. Washing: Spiral washer
Feed the raw sand less than 2mm into the raw ore bin, and directly feed it to the spiral washing machine to remove the impurities on the surface. The silt floating surface can be overflowed together with the water. The coarse ore particles sink to the bottom of the tank, and the bottom flow enters the vibrating screen.

2. Screening: Vibrating screen
The vibrating screen adopts a layer of screen mesh with a mesh size of 1mm. Materials larger than 1mm are transported to the side by belt conveyor and become waste sand. Materials smaller than 1mm are fed to the feeding port of the spiral chute by sand pump.

3.Separation: Spiral chute, Shaking table, Magnetic separator

  • Gravity separation mainly removes light minerals. The medium ore and concentrate in the spiral chute enter the shaking table together for separation, and the tailings are discharged together. The final concentrate in the shaker is dried naturally in the sun.
  • Magnetic separation mainly separates iron minerals. Finally, all the ore concentrates after drying are sent to a magnetic separator with a bucket elevator to separate ilmenite and hematite.
  • Then the non-magnetic minerals will be sent to the electric separator with another bucket elevator, and the rutile with zircon and conductivity will be separated.

Zircon Sand Processing Plant Solutions & Flow Design

Equipment List

Spiral sand washer
Spiral sand washer
spiral chute
spiral chute
High-Frequency Vibrating Screen
Vibrating Screen
gold shaking table
Gold shaking table
slurry pump
Slurry pump
magnetic separator
Magnetic separator
Belt conveyor
Belt conveyor
Electrostatic separator
Electrostatic separator
