Gold Sluice Box
A gold sluice box is one of the most popular gold mining equipment, consisting of a steel structure and carpets—customizable various-sized sluice boxes. It is mainly used in placer gold mining scenarios such as seaside, riverside, and beach sand. It is particularly good at recovering fine-grained gold minerals such as capillary gold and thin-skin gold.
Application: The gold sluice box is normally used in rock/ alluvial gold mining processing plants; it’s been widely used to recovery gold directly together with trommel screens or rotary scrubbers. It can also be used for tailings reselection and river sediment purification.
Products display
introduction of gold sluice box
Gold sluice box is a gravity separation machine for the recovery of fine gold, the most common gold mining processing plant equipment. Widely used to extract gold particles from various placer/alluvial gold ore, tailings, waste ores or other gold-containing materials. The gold sluice box has a certain inclination angle, so that the water flow can drive the ore to move along the chute. At the same time, heavy particles (such as gold particles) gradually settle at the bottom of the chute due to gravity during the movement.
The sluice box can be used to separate gold particles from other light minerals, usually after centrifugal concentrator, shaker table or ore washers for enrichment and extraction of fine gold. It has the advantages of high recovery rate and low energy consumption, and can effectively solve the problem of fine-particle gold enrichment, providing an economical and reliable separation solution for placer mining.
Working principle of gold sluice box
The slurry is fed from above and scoured by the water flow in the inclined trough. Lightweight gangue is washed away, while high-density minerals (such as gold particles) settle due to gravity and embed themselves in the grooves of the trough bottom or the gaps between the grates. The machine is regularly shut down to flush and extract the concentrate, achieving continuous separation.
why choose JXSC gold sluice box
Features and advantages of gold sluice box
1. Low price, no need for electric power, light weight, easy installation.
2. The structure is simple, does not require complicated technology or much labor, and is easy to operate and maintain;
3. The design is light and easy to disassemble and transport, making it easy to move and use between different gold mining sites;
4. It can adapt to different terrain conditions, such as being used in streams, river beds, etc.；
5. In gold processing plant, install the gold mat/layer to catch fine and coarse gold;
6. The gold sluice box can be equipped with a rotary scrubber, trommel screen, centrifugal concentrator, shaking table or other combination of equipment to separate gold.
models & specifications
| Model | Length | Width | Capacity |
| JXSC-4000×1000 | 4000mm | 1000mm | 10-15TPH |
| JXSC-6000×1000 | 6000mm | 1000mm | 20-25TPH |
