5TPH Rock And Placer Gold Recovery Plant In Ethiopia

1. Gold Washing: Trommel screen

The raw ore larger than 100mm enters the hopper with a screen. Trommel screen with screen bar washing the material without sticky clay and separating the stones. Among them, material of 0-3mm enters the centrifuge, material of 3-20mm goes directly to the gold chute, and the material larger than 20mm is transported to the jaw crusher by a belt conveyor.

2. Crushing stage: Jaw crusher, Hammer crusher

The jaw crusher roughly breaks the 20-150mm material into a size of 0-40mm, and then transports it to the hammer crusher with a belt conveyor for fine crushing, so that the material size is 0-2mm.

3. Separation stage: Gold centrifugal concentrator, Shaking table, Sluice box

The tailings of the centrifugal concentrator go to the gold chute to recover gold, and the materials from the hammered 0-2mm are directly sent to the shaker table for separation.

4. Melting stage: Gold melting furnace

The gold concentrate from the shaker and the gold chute enters the gold melting furnace to obtain gold bars.

We support customized placer or rock gold recovery plant. Contact us to design processes and equipment.
